【Parameters】
| Input | Operating Voltage | 198-264Vac 50Hz/60Hz | ||||||
| Rated Input Voltage | 220-240Vac 50Hz/60Hz | |||||||
| DC Input Voltage range | 200-240Vdc | |||||||
| Input Current | 0.35A Max. | |||||||
| Input Inrush Current | <25A (Half current pulse width100μs) @230Vac | |||||||
| Power factor(@230V100% load) | ≥ 0.95 | |||||||
| Total harmonic distortion | Typical:15% (@230Vac, 100% load) | |||||||
| Stand-by power | ≤0.5W (@230Vac) | |||||||
| Efficiency(@230Vac,100% load) | 88% | |||||||
| Wiring Method | Wire cross section:0.75-2.5mm2 | |||||||
| Loop-in&Loop-out quantity | 22PCS(@230Vac) | |||||||
| Automatic circuit breaker (Calculate current in the wire) | type | B10 | B13 | B16 | B20 | B25 | / | |
| Number | 20 | 25 | 30 | 40 | 50 | / | ||
| type | C10 | C13 | C16 | C20 | C25 | C32 | ||
| Number | 28 | 40 | 45 | 55 | 70 | 90 | ||
| Output | Operating mode | Constant Current | ||||||
| Load type | LED | |||||||
| Ripple requirement (Flickering or Flickering-Free) | Flicker value: less than 5% for the whole dimming range | |||||||
| Start-up time | <1s (@230Vac) | |||||||
| No-load output voltage | 72V DC Max. | |||||||
| Load output voltage range | 9-58Vdc | |||||||
| Full load output power | 50W Max. | |||||||
| Load output current | 700mA(9-58Vdc) 800mA(9-58Vdc) 850mA(9-58Vdc) 900mA(9-56Vdc) 950mA(9-53Vdc) 1000mA(9-50Vdc) 1050mA(9-48Vdc) 1100mA(9-45Vdc) 1150mA(9-43Vdc) 1200mA(9-42Vdc) 1250mA(9-40Vdc) 1300mA(9-38Vdc) 1400mA(9-36Vdc) | |||||||
| Output | Constant current/voltage Precision | Constant Current Precision ±5% | ||||||
| Wiring method | Wire cross section:0.75-1.5mm2 | |||||||
| Control Method | Working frequency | 2.4-2.48GHz | ||||||
| Transmitting power | +8dBm Max. | |||||||
| Transmission distance | Point-to-point transmission range 30m Max. | |||||||
| Modulation mode | O-QPSK PHY | |||||||
| Exception Protection Requirements | Output over temperature protection | Yes, without a self-recovery function | ||||||
| Output short circuit protection | Yes, without a self-recovery function | |||||||
| Operating Environment | Operating temperature/ humidity | -25℃~50℃ Humidity: 85% (Non-condensing) | ||||||
| Storage temperature/ humidity | -40℃~80℃, Humidity: 85% (Non-condensing) | |||||||
| Max. case temp(Tc) | 85℃ | |||||||
| Safety & EMC | EMC standard | EN55015 EN61547 EN61000-3-2 EN61000-3-3 | ||||||
| Safety standard | EN61347-1 EN61347-2-13 | |||||||
| Certification | CE | |||||||
| Withstand voltage | 3750Vac, 5mA, 60s (Input “L N”- Output “SEC”) | |||||||
| Others | Degrees of protection | IP20 | ||||||
| Type of protection | Class I | |||||||
| Installation type | Independent installation | |||||||
| Dimension | 185*79*30mm | |||||||
| Packaging requirement | PE bag + white box + manual + partition + outer box (K=A) | |||||||
| Weight | 262.6±5g | |||||||
| Life | 5 year @Ta full load | |||||||
| Note: All parameters are tested at the input voltage of 230Vac and 25 degree environment unless specified. | ||||||||
【Dimension】
【Wiring】
【Derating】
【Output current setting】
| Current(mA) | DIP | Pomax(W) | Uout(V) | |||||
| 1 | 2 | 3 | 4 | |||||
| 700 | - | - | - | - | 40.6 | 9～ | 58 | |
| 800 | ON | - | - | - | 46.4 | 9～ | 58 | |
| 850 | - | ON | - | - | 49.3 | 9～ | 58 | |
| 900 | - | - | ON | - | 50.4 | 9～ | 56 | |
| 950 | ON | ON | - | - | 50.4 | 9～ | 53 | |
| 1000 | ON | - | ON | - | 50.0 | 9～ | 50 | |
| 1050 | - | ON | ON | - | 50.4 | 9～ | 48 | |
| 1100 | - | ON | - | ON | 49.5 | 9～ | 45 | |
| 1150 | ON | ON | ON | - | 49.5 | 9～ | 43 | |
| 1200 | ON | ON | - | ON | 50.4 | 9～ | 42 | |
| 1250 | ON | - | ON | ON | 50.0 | 9～ | 40 | |
| 1300 | - | ON | ON | ON | 49.4 | 9～ | 38 | |
| 1400 | ON | ON | ON | ON | 50.4 | 9～ | 36 | |
【Application】
【ATTENTION】
1) The LED driver must be connected to the load before turning on the input power, otherwise, the LED driver may be damaged.
2) After the LED drive input is powered off, there will be a residual voltage at the output, which can be maintained for about 3 minutes.
